Cooling air dryer machine CA-4
Basic parameters:
External dimensions 2000*900*1750mm
Tunnel maximum width: 520mm
Tunnel maximum height: 250mm
Noise level ≤70db
Equipment weight：520kg
Frame material：SUS 304 stainless steel
Water supply:
Tap water
Interface: DN25
Pressure: 2-6 bar
Water tank: 200L
Drainage:
Direct drainage with manual valve
Drain pipe diameter φ76
Refrigeration:
Refrigeration method: Ice throwing/external chiller
Water pump power 3kw
Drying:
Drying: Centrifugal fan
Fan power: 3*1.1kw 1*2.2kw
Power supply:
Voltage AC220/380V 50/60HZ 3PHASE
Total power: 12KW
